FORD AOD PERFORMANCE AUTOMATIC TRANSMISSION WITH CONVERTER LEVEL-3

Up to 500hp / 500 ft-lbs Torque

(0) Reviews: Write first review
FORD-AOD-L3
Small Block Engines only Transmission with Torque Converter
Availability: Custom built to order (No core charge)
Shipping: Truck Freight
Pricing: $6,895.00

Qty:

Description

FORD AOD PERFORMANCE TRANSMISSION WITH CONVERTER LEVEL-3

Small Block Engines only Transmission with Torque Converter

  • No core charge, outright purchase
  • Up to 500hp
  • Up to 500ft-lbs Torque
  • Converter: 10” Custom Built Non-Damper Style
  • Stall: 2600-3200


    • SPECIFICATIONS:

  • Master Overhaul Kit with New Steel Plates
  • TransGo Reprogramming Shift Kit
  • Raybestos Frictions
  • New Filter
  • New Bearing Kit
  • New Bushing Kit
  • Reverse Drum with Mechanical Diodes
  • New Low Spring & Roller
  • Alto Red Eagle Wide Overdrive Band
  • High Capacity 4 Plate Intermediate Clutch
  • High Capacity Direct Clutch
  • Updated 3rd Accumulator Piston
  • Extra Capacity Servo
  • Heavy Duty Remanufactured Pump
  • Chrome Pan
  • Transmission Mount
  • Custom 360 degree Adjustable Shift Linkage Arm



    • NOTE:All transmissions are custom built by 1 of 5 Master Techs from start to finish and DYNO tested with torque converter for the equivalent of 100 miles to insure that transmission and converter package are in perfect operating condition before they are packaged and shipped out.

    Gear Ratios

    1st - 2.40
    2nd - 1.47
    3rd - 1.00
    4th - 0.67

    Dimensions

    Measurements are taken from mounting surface where trans meets engine block to the tip of the tailshaft

  • Total Length: 32 1/2″ ~ Short Tail
  • Total Length: 33 1/2″ ~ Long Tail
  • Distance to trans mount center: 23″

    • Details

    • FORD-AOD-L3
    • FORD-AOD-L3
    • Custom built to order (No core charge)
    • New

    Categories

    Shipping Information

    • Item Requires Shipping
    • 300.0 lbs.
    • W38.0000” x H24.0000” x L48.0000”
    • $150.00
    • Truck Freight
