1962-1967 CHEVROLET NOVA/CHEVY II ALUMINUM RADIATOR W/BRUSHLESS FAN & SHROUD

LS Supercharged Swap Fan Kit

1-1673-212LSBLACINXX
Pricing: $3,198.00

Qty:

Description

1962-1967 Chevrolet Nova / Chevy II Aluminum Radiator (LS-SUPERCHARGED Swap) - 1-1673-212LSBLACINXX

  • INCLUDES: Upgraded Radiator, Dual chamber shroud, Dual-Spal brushless fans, Intercooler, A/C Condenser, overflow tank, intercooler reservoir and 185-Degree Sensor

    Due to the lack of room in front of the radiator for the intercooler and the AC condenser, this system will only fit for applications with PIN MOUNTED HOODS. You will need to remove the hood latch attachment to make room for the AC condenser and intercooler.

    YEAR / MAKE / MODEL:

  • 1967 CHEVROLET CHEVY II
  • 1966 CHEVROLET CHEVY II
  • 1965 CHEVROLET CHEVY II
  • 1964 CHEVROLET CHEVY II
  • 1963 CHEVROLET CHEVY II
  • 1962 CHEVROLET CHEVY II
  • SPECS

    SKU:1-1673-212LSBLACINXX
    Item #:1-1673-212LSBLACINXX
    Brand: Wizard Cooling Inc
    Year Make Model:
    1967 CHEVROLET CHEVY II
    1966 CHEVROLET CHEVY II
    1965 CHEVROLET CHEVY II
    1964 CHEVROLET CHEVY II
    1963 CHEVROLET CHEVY II
    1962 CHEVROLET CHEVY II
    Engine: LS Swap (SUPER CHARGED)
    Application Nuance: Passenger Side Inlet
    PRODUCT NOTES: LS Swap (SUPER CHARGED)
    Shroud YES/NO: Yes
    Electric Fan YES/NO: Yes
    CRITICAL THICKNESS: 6 1/2 IN
    THICKNESS OF CORE: 2 3/4 IN
    Electric Fan Type: Brushless
    Core Thickness: 2 3/4 IN
    TRANSMISSION OIL COOLER INCLUDED: Yes
    MOUNTED AC CONDENSER: Yes
    OUTLET LOCATION: Passenger Side
    INLET LOCATION: Passenger Side
    Electric Fans: Yes
    TUBE INSIDE DIAMETER: 1 1/4 IN
    TRANSMISSION OIL COOLER TYPE: Plate
    TRANSMISSION OIL COOLER PLATE QUANTITY: 5
    TOTAL CFM (ALL FANS): 2880
    TANK MATERIAL: Aluminum
    CORE MATERIAL: Aluminum
    OUTLET HEADER WIDTH: 3 IN
    CORE ROW QUANTITY: 2
    OUTLET HEADER LENGTH: 22 IN
    NUMBER OF ELECTRIC FANS: 2
    MOUNTING TYPE: Flange
    INLET HEADER WIDTH: 3 IN
    INLET HEADER LENGTH: 22 IN
    INLET DIAMETER: 1 3/8 IN
    FAN DIAMETER: 11 IN
    ENGINE OIL COOLER INCLUDED: No
    DOWN FLOW OR CROSS FLOW TYPE: Down Flow
    CUBIC INCHES OF CORE: 980
    CORE WIDTH: 22 IN
    OUTLET DIAMETER: 1 5/8 IN
    CORE HEIGHT: 15 1/2 IN
    FINISH: Aluminum
    SHROUD TYPE: Non-Integrated
    Specifications
    Chevrolet - Nova / Chevy II - 1962-1967
    Radiators - Chevrolet - Nova / Chevy II
    Radiators - Chevrolet
    Radiators
    SUPERCHARGED Swap Systems
    Specifications
    1962-1967 Chevrolet Nova / Chevy II (LS Swap- SUPERCHARGED)

    Details

    • 1-1673-212LSBLACINXX
    • 1-1673-212LSBLACINXX
    • Wizard Cooling
    • New

    Categories

    Shipping Information

    • Item Requires Shipping
    • 60.0 lbs.
    • W24.0000” x H12.0000” x L34.0000”
