1967-1969 CHEVROLET CAMARO/Z28/FIREBIRD LS SWAP ALUMINUM RADIATOR W/STANDARD FAN & SHROUD

LS Swap Fan Kit

1-370-212LSBLACINXX
Pricing: $3,298.00

Qty:

Description

1967-1969 Chevrolet Camaro/ Z28/ Firebird (LS-SUPERCHARGED Swap) - 370-212LSBLACINXX

INCLUDES:

  • High performance radiator with 2 rows of 1.25" tubes, with a core thickness of 2.75"
  • Dual Chamber Shroud for improved airflow through the shroud
  • Dual 12" Spal BRUSHLESS fans, moving 3800 CFM
  • Intercooler
  • A/C Condenser
  • Intercooler reservoir
  • Overflow/ Recovery tank
  • 185-Degree Sensor
  • Built in transmission cooler



    NOTE: CORE SUPPORT IS NOT INCLUDED
  • SPECS

    SKU:1-370-212LSBLACINXX
    Item #:1-370-212LSBLACINXX
    Brand: Wizard Cooling Inc
    PRODUCT NOTES: LS Swap (SUPER CHARGED)
    Shroud YES/NO: Yes
    Electric Fan YES/NO: Yes
    CRITICAL THICKNESS: 6 1/2 IN
    Performance Ranking: Absolute Best
    THICKNESS OF CORE: 2 3/4 IN
    Shroud: Yes
    Electric Fan Type: Brushless Motor
    TRANSMISSION OIL COOLER INCLUDED: Yes
    MOUNTED AC CONDENSER: No
    OUTLET LOCATION: Passenger Side
    INLET LOCATION: Passenger Side
    CORE ROW QUANTITY: 2
    Expansion Tank Included: No
    Electric Fans: Yes
    CORE MATERIAL: Aluminum
    TUBE INSIDE DIAMETER: 1 1/4 IN
    TOTAL CFM (ALL FANS): 3600
    TANK MATERIAL: Aluminum
    CORE WIDTH: 23 IN
    CUBIC INCHES OF CORE: 1147
    OUTLET HEADER WIDTH: 3 IN
    OUTLET HEADER LENGTH: 18 1/2 IN
    OUTLET DIAMETER: 1 5/8 IN
    MOUNTING TYPE: Flange
    INLET HEADER WIDTH: 3 IN
    INLET HEADER LENGTH: 18 1/2 IN
    INLET DIAMETER: 1 3/8 IN
    FAN DIAMETER: 12 IN
    ENGINE OIL COOLER INCLUDED: No
    DOWN FLOW OR CROSS FLOW TYPE: Cross Flow
    NUMBER OF ELECTRIC FANS: 2
    CORE HEIGHT: 18 1/2 IN
    SHROUD TYPE: Non Integrated
    Specifications
    Chevrolet - Camaro/ Z28/ Firebird - 1967-1969
    Radiators - Chevrolet - Camaro/ Z28/ Firebird
    Radiators - Chevrolet
    Radiators - Pontiac
    Radiators
    SUPERCHARGED Swap Systems
    Specifications
    1967-69 Camaro/ Firebird (Supercharged LS Swap Radiator)

    FITMENTS

    Year Make Model:
    1969 PONTIAC FIREBIRD
    1969 CHEVROLET CAMARO
    1968 PONTIAC FIREBIRD
    1968 CHEVROLET CAMARO
    1967 PONTIAC FIREBIRD
    1967 CHEVROLET CAMARO

    VIDEO

    Details

    • 1-370-212LSBLACINXX
    • 1-370-212LSBLACINXX
    • Wizard Cooling
    • New

    Categories

    Shipping Information

    • Item Requires Shipping
    • 60.0 lbs.
    • W24.0000” x H12.0000” x L34.0000”
